Tyler Kerpsack's Dlive + Waves Show File for Mixing Worship (samples/IR's included)

This is the complete package of everything you see from my instagram videos.  This is my latest 2025 files packed with everything you need to understand my workflow and how I am processing channels, groups, etc.



Included you will find:

-Dlive Show File

-Waves Superrack Show File

-Kick + Snare Samples from my Roland TM-2

-Reverb IR's from my vocal chain

-Virtual Playback Tracks



**To import the DLive file you must first put a usb into the console, transfer any show to the usb, and THEN plug your usb into a computer and drag my file into the shows folder.  If you forget to do this, nothing will show up.



**Note I used a DLive c3500 surface for this file.  I also used a Roland TM2 to fire samples, and am running all my waves off of a single Server-One at about 80% CPU.



This file is broken up into the following console sections:



LEFT CONSOLE SECTION

(A) DRUMS:

Kick In

Kick Out

Kick Trigger

Snare Top

Snare Bottom

Snare Trigger

Tom 1

Tom 2

Tom 3

Tom 4

HiHat

Overhead L

Overhead R



(B) INSTRUMENTS:

E Bass

Distorted E Bass

Acoustic

Electric Guitar 1

Electric Guitar 2

Keys 1

Tracks Percussion

Tracks Bass

Tracks Pads

Tracks Synths

Tracks Guitars

Tracks Vocals



(C) SPEAKING MICS / PLAYBACKS

Host 1

Host 2

Pastor 1

Pastor 2

RESI Playback

Pro Presenter

Spotify



(D) VOCALS (Non-tune for monitors only)

HH1

HH2

HH3

HH4

HH5

HH6



(E) Band Talkbacks

MD1 Keys

MD2 EG 1

MD3 Bass

MD4 EG 2

MD5 Drums



(F) KLANG Aux Groups

Spare

Spare

Drum Kit

All Tracks

All Speakers

All Playback

All MD's

All Click

Crowd





RIGHT CONSOLE SECTION

(A) DCA'S

Drums

Gtrs

Keys

Tracks

Vox

FX

Playback

Broadcast (Matrix)

Subs (Aux)

Main (LR)



(B) Vocals + FX Returns

HH1

HH2

HH3

HH4

HH5

HH6

Vox Verb

Vox Delay

Band Verb

Gtr Verb

Drum Verb

Snare Verb



(C) Groups

Drum Group

Drum Comp (Parallel)

Inst Group

Vox Group



(D) Resi Aux Sends

FOH Feed

Tracks

Pastor

Host

Lead Vox

MD

Video

Keys

Crowd 1

Crowd 2

Click



(E) Misc

Guide (Resi Aux)

Spanish Translation (Resi Aux)

Portuguese Translation (Resi Aux)

Translation 1 (channel)

Translation 2 (channel)

Comm's PGM (matrix)

Comm's Click (matrix)

Wedge (matrix)

Broadcast (matrix)



(F) FX Sends/Returns

Drum Verb (send)

Band Verb (send)

Vocal Verb (send)

Vocal Delay (send)

Snare Verb (send)

Guitar Verb (send)

Drum Verb (return)

Band Verb (return)

Vocal Verb (return)

Vocal Delay (return)

Guitar Verb (return)

Snare Verb (return)





When opening Waves, you will be asked to load the included IR for the vocal reverb.  Also when going over to the layers section, make sure to select "Custom" where all my layers will be organized into "Drums, Inst, Vocal, Buss" on Overview 1 and "Vocals" on Overview 2.  Note the scenes are set to recall Waves tune keys.  I recommend a stream deck to control it.  I have included that file as well.
